Mafell 916201 PSS3100SE Panel sawing system

Mafell 916201 PSS3100SE Panel Saw System

Now a total of 5 years warranty on Mafell PSS 3100 Machines(*)

(*) Now a total of 5 years warranty on machines after registration of your machine, using the enclosed warranty form.

Features Panel sawing system PSS 3100 SE

• Mobile Panel Saw PSS 3100 SE
• Optimal dust extraction
• Mobile slab saw
• Cutting cementitious slabs The PSS 3000 / PSS 3100 SE from MAFELL are the first self-propelled and mobile slab saws.
• The unique features of the construction ensure that hardly any dust is released when cutting.
• The PSS 3100 SE features an innovative saw blade cover.
• In combination with the integrated extraction channel and the S 50 M vacuum cleaner, dust particles are almost completely extracted.
• With the newly developed diamond saw blade, the PSS 3100 is well suited for cutting cementitious materials.
• High-quality electronics, through speed control and a quiet start-up, increases safety and adjusts the speed for different materials, e.g. plastic, fiberboard or aluminum.
• Electronics also ensure constant speed under load and overload protection.

Technical data of PSS 3100 SE

• Cutting depth 0 - 45 mm
• Saw blade max. 160 mm
• Saw shaft 20 mm
• No load speed 2600-5200 1/min
• Cutting length 3100 mm
• Feed rate 0.07 - 0.34 m/s
• Backwash speed 0.42 m/s
• Cutting speed 28 m/s
• Universal motor 230 V / 50 Hz
• Power consumption 1490 W
• Power output 850 W
• Extraction connection 35 mm
• Weight 17 kg

Standard included:

• Panel saw PSS 3100 SE Best. No. 916201
• Supplied with 1 saw blade-HM Best. No. 092533 160 x 1,2/1,8 x 20 mm, Z 24, WZ, for universal use
• 1 Hex screwdriver Best. No. 093278
• 1 Connection cable 4 m

Attention! A Demo of this machine is possible in NL and BE! More info you can ask our sales department via our contact form!
