AirFlux AIR-12020 VORTEX 4 Cyclone Dust Extractor 400V 4pk

AirFlux AIR-12020 VORTEX 4 Cyclone Dust Extractor 400V 4pk

The Air Flux® VORTEX 4 is designed for professional workshops where maximum extraction performance is essential.

Key Features

• Powerful 4 PK induction motor for high extraction performance

• Airflow of 3,200 m³/h and maximum vacuum of 2,500 Pa

• Suitable for installations with long duct runs and high pressure drops

• Highly efficient cyclone technology for pre-separating the majority of dust and chips

• Automatic filter cleaning system for consistent filter performance

• Manual filter cleaning function via the control panel

• Integrated pressure gauge for continuous monitoring of vacuum pressure and filter contamination

• Wireless remote control for easy remote operation

• Spacious metal collection bin with a capacity of 203 liters

• Collection tank can be quickly removed thanks to two quick-release clamps on the front

• Integrated guide system with ball bearings for smooth removal of the collection tank

• Air compensation connection eliminates the need for a metal support basket for the collection bag

• Practical quick-release coupling for easy disconnection of the air compensation connection

• Powerful turbine with a diameter of 400 mm

• High-quality cartridge filter with a filter surface area of 7.5 m²

• Large collection capacity for less frequent emptying

• Designed for professional woodworkers who demand high performance, reliability, and ease of use

• Combination of cyclone technology, automatic filter cleaning, integrated pressure gauge, and wireless remote control for optimal ease of use

Technical Specifications

• Voltage: 400 V

• Motor power: 4 pk

• Motor type: induction motor

• Airflow: 3,200 m³/h

• Static pressure: 2,500 Pa

• Turbine diameter: 400 mm

• Filtration fineness: 1 µm

• Dust extraction port diameter: 100 mm

• Number of dust extraction ports: 3

• Main exhaust port: 200 mm

• Weight: 166 kg
