Bahco BH730 Hydraulic press 30 tons
Description
- Heavy duty structure with round shapes, exclusive design
- Large, glycerine-filled pressure gauge at eye level: easy to read
- Two-speed pump with built-in overload safety valve
- Sliding and hard chrome plated piston
- Quick to operate with the pedal or lever
- Rulers for easy centering of the piston on the part being pressed
- With two V-blocks that can be used on either the V-side or the flat side, depending on what is needed
- Self-centering pins for the table
- The table of the press can be easily moved up and down thanks to the winch with rotating lever
- Pedal with non-slip rubber
- Supplied with 8 pressure pins and a clamping plate
- Insulated levers
- Tool holder at bottom
- CE certified according to 2006/42/EC
Specifications
- A = 960 mm
- B = 700 mm
- C = 1776 mm
- D = 1810 mm
- E = 695 mm
- F1 = 140 mm
- F2 = 1020 mm
- F = 137 mm
- G = 10 mm
- H = 200 mm
- L = 80 mm
- M = 195 mm
- X = 855 mm
- Y = 990 mm
- Weight 189 kg
- Press capacity 30,000 kg
More Information
| EAN | 7314150235667 |
|---|---|
| Order Number | BH730 |
| Manufacturer | Bahco |
| Warranty | 1 year |
