Bahco TAM12200 Electronic torque and goniometer

Bahco Electronic torque and goniometer TAM12200

Features

• Converts any standard ratchet, sliding pipe wrench or articulated tool into a digital moment and angle measuring instrument
• Momentary units in Nm, ft.lb, lb.in and angular units in degrees
• Range varies from 1.5 to 340 Nm and from 13 in.lb to 250 ft.lb
• Can be used clockwise and anti-clockwise at temperatures between -10ºC and 60ºC
• Memory for 50 operations and for up to 9 preset values
• Modes: peak and trace
• Automatic switch-off
• 2 AAA alkaline batteries included
• More information in the manual
• ±4% clockwise and anticlockwise
• Visual (dual LED LCD display) and audible signal
• Fixed ¼" to ½" square connections
• Supplied in a portable zippered fabric pouch with foam covering in a cardboard box
• Supplied with manufacturer's declaration of conformity, traceability to international standards and CE marking
• 2004/108/EC, ISO 6789

Specifications

• Scale: 1 Nm
• Square: 1/2 in
• Square: 1/2" mm
• Doelbereik: 0-360°
• Coupling range: 7.4-147.5 lb-ft
• Torque range: 88.5-1770 lb-in
• Torque range: 10-200 Nm
• Weight: 250 g
• Weight: 0.250 kg
• Total height: 85 mm
• Head, Width: 80 mm
