Bahco 14F-3/4 Fixed square head with rectangular connector

Bahco Fixed square head with rectangular connector 14F-3/4

Features

• Fixed square sockets for better accessibility in width and height compared to ratchet sockets
• The insert is secured to the torque wrench with a spring-loaded retractable pin
• The range extends from 9 x 12 to 27 x 36 sockets, from 1/4 to 1 inch square sockets and from a maximum torque of 30 Nm to 2500 Nm
• Suitable for 7465, 74W9, 74W14, 74P9, 74P14, IZO-D, TAW9, TAW14, TAW24, TAWM9, TAWM14 and TAWM24 keys
• For sizes with * in the moment length, the moment setting must be calculated

Specifications

• Length: 18 mm
• Drive square: 3/4"
• Square: 3/4 in
• Weight: 390 g
• Weight: 0.390 kg
• Width square: 14 mm
• Overall length: 69 mm
• Width: 40 mm
• Height: 25 mm
• Working length: 25 mm
• Head, Width: 40 mm
