Bahco 97-15/16 Imperial Insert with Open-end and rectangular connector

Bahco Imperial Insert with Open-end and rectangular connector 97-15/16

Features

• The insert is secured to the torque wrench with a spring-loaded retractable pin
• The range includes 9 x 12 and 14 x 18 holders and varies from 1/4 to 1 1/4 inch openings and from 6 to 360 Nm
• For sizes with * in the moment length, the moment setting must be calculated
• Suitable for 7465, 74W9, 74W14, 74P9, 74P14, IZO-D, TAW9, TAW14, TAWM9 and TAWM14 wrenches

Specifications

• Diameter: 15/16 mm
• Length: 12 mm
• Max. Coupling force: 160 Nm
• Weight: 60 g
• Weight: 0,06 kg
• Square width: 9 mm
• Overall length: 45 mm
• Width: 36 mm
• Height: 8 mm
• Working length: 18 mm
• Length:*25 mm
• Head, Width: 53 mm
