Bahco 9R-3/8 Round ratchet head with rectangular connector

Bahco Round ratchet head with rectangular connector 9R-3/8

Features

• Round reversible ratchet with 45 teeth
• The insert is secured to the torque wrench with a spring-loaded retractable pin
• The range extends from 9 x 12 to 27 x 36 sockets, from 1/4 to 1 inch square sockets and from a maximum torque of 30 Nm to 2500 Nm
• Suitable for 7465, 74W9, 74W14, 74P9, 74P14, IZO-D, TAW9, TAW14, TAW24, TAWM9, TAWM14 and TAWM24 keys

Specifications

• Length: 12 mm
• Drive square: 3/8
• Max. Coupling force: 135 Nm
• Square: 3/8 in
• Weight: 200 g
• Weight: 0.2 kg
• Square width: 9 mm
• Overall length: 53 mm
• Width: 19 mm
• Height: 21 mm
• Working length: 17,5 mm
• Head, Width: 38 mm
