Belmash BEL-2000UNI Universal woodworking machine sawing and planing!
4810997000176
Articlenr.
BEL-2000UNI
Expected delivery time 3 to 6 working days
- The Trusted Shops Buyer Protection*
- 14 days to withdraw (see conditions)
- Fast and secure online payments
- Directly to:
- Product description
- More Information
- Trusted Shops Reviews
Product description
Belmash BEL-2000UNI Universal woodworking machine sawing and planing!
Features
- These portable and compact planing and sawing machines 230V are unique in the market and one of a kind
- They work against all other machines of its kind with very powerful induction motors
- An induction motor has 30% more power than a carbon brush motor and is over 40% quieter
- It is also maintenance-free, as there are no carbon brushes to replace
- Furthermore, they are driven in an industrial way by means of poly-belts instead of classical V-belts
- The construction of the frame is also very unique and robust as it is made of sheet steel of 3.5mm thickness
- Together this guarantees excellent performance, but also optimal resistance for your machine
- Very fast change from planing to sawing function by moving the belt
- The unique thing about these models is that they work with a separate knife block for each operation
- The independent drive provides the ideal speed for planing and sawing
- Also turn to safety so the planer and saw are separate
- Thanks to the micro-lifting system of the planing tables, the planing depth can be set very precisely and smoothly, but the tables can also be closed completely in a short space of time
- By completely closing the tables, the saw table has a large working area
- This Universal 2.0 has a very clear and accurate scale for each setting
- The guide can be locked both in front of and behind the work table, ensuring stable and precise work
- It can also be set to angle or miter with very clear readout, and this for both the planer and saw function
- For the saw there is also a miter guide with clear degree indication
- The machine is equipped for working with rabbit cutters up to 10mm thick
- The high-quality construction of these compact machines, such as thick sheet steel, direct drive, induction motors, high-quality ball bearings, large and robust adjusting and rotating levers give these machines an enormous ease of use with excellent performance and an optimal service life
- 230V, 2.8 HP powerful induction motor
- 200mm planing width
- 97mm cutting height
- Portable and compact planer and saw
- Solid sheet steel tables 3.5mm thick
- Driven by Poly-V belt
- Very fast change from planing to sawing function by moving the belt
- Guide can be clamped in front or behind for stable and precise work
- Independent drive for the ideal speed for each operation
- Can work with grooved cutters up to 10mm thick
Technical data
- Planing width 200mm
- Planing spindle speed 6000/2850 RPM Motor 230V, 50Hz, 2000W
- Saw blade 250mm
- Machine weight 36 Kg
- Cutting depth 97mm
- Dimensions 732x491x358mm
- Planing cutter 0-3mm
- Range of sawing or planing tilts 0-45
- Dimensions work table 700x474mm
- Packaging dimensions 750x509x251mm
Includes
- Clamping device
- Saw guide
- Saw blade with splitting wedge
- Ruler
- Cover plate
- Handle (thumbscrew)
- Mitre guide
- Insert
- Planing bits in knife block
- Bracket
- Operating manual
Temporarily with thickness guard!
More Information
EAN | 4810997000176 |
---|---|
Ordernumber | BEL-2000UNI |
Manufacturer | Belmash |
Voltage | 230 V |
Warranty | 1 year |
