Bonfix 2002720 Alu-press system pipe 16 x 2.0 roll 10 meters

Bonfix 2002720 Alu press system pipe 16 x 2.0 roll 10 meters

Special features.

• The Bonfix multi-layer pipe is a high-quality plastic-aluminum water pipe that combines flexibility with dimensional stability. This pipe is part of the BONFIX Alu-press range and is suitable for both potable water installations and central heating systems, including low and high temperature applications.
• Thanks to its flexibility, this pipe is easier to process than traditional copper pipes. The pipe can be effortlessly bent using a bending spring, permanently retaining its bent shape. This makes the pipe ideal for installing in confined spaces, such as crawl spaces, technical cabinets or under sinks.

Applications

• 1. Central heating systems (central heating):
• Radiators
• Underfloor / wall heating
• Connecting pipes between distributors and radiators
• Well suited due to the oxygen-tight aluminum layer → prevents corrosion in boilers and radiators
• 2. Domestic hot water systems (cold and hot):
• Cold potable water
• Hot potable water
• Circulation pipes (if within temperature and pressure limits)
• KIWA/KOMO approved → suitable for potable water installations
• 3. Sanitary:
• Pipes to sink, shower, bath, toilet
• Suitable for incorporation in walls, floors and ceilings
• 4. Industrial and utility applications:
• Installations in commercial buildings.
• Low-temperature heating systems
• Cooling systems with water
• 5. Renovation & new construction:
• Thanks to the flexibility of the roll (10 m):
• Ideal for renovation and remodeling
• Few couplings required → less risk of leaks
• Easy to work into walls/floors

Advantages

• Low coefficient of expansion due to aluminum core → less action than pure plastic
• Light and flexible, yet retains its shape
• Combines well with Bonfix press fittings for a guaranteed system

Points of attention

• Make sure you use the right pressing machines and appropriate pressing jaws, because the system guarantee condition states that pipe and fitting must be from Bonfix and mounted according to the installation instructions.
• Since it is a roll (10 m), consider the required length for your installation and whether cutting/finishing is required.
• Check if the specification (16×2.0) fits your installation (e.g. pressure, temperature requirement, allowable bending radius, insulation requirement).
• Also, choose the appropriate fittings/fittings compatible with this pipe system.

Technical data.

• Size: Ø 16 mm
• Wall thickness: 2.0 mm
• Roll length: 10 meters
• Application: For drinking water and central heating installations, both in low and higher temperature systems.
• Quality marks: KIWA and KOMO quality mark available.
• Other properties: 100% oxygen tight (limiting corrosion).
• Maximum working pressure: 10 bar (at 20 °C) for continuous use; briefly higher temperature possible.
• Maximum continuous temperature: +70 °C, temporarily up to +95 °C.
