Bosch DIY 06033A9301 PBH 2100 SRE Drill Hammer 550 watts

Bosch 06033A9301 PBH 2100 SRE Drill Hammer 550 watts

Special features

• Light and powerful - effortless drilling, hammering and chiseling
• Motor of 550 W and pneumatic hammer mechanism with 1.7 J for general jobs
• SDS plus drill chuck for tool-free drill change and SDS drill chuck adapter for round shank drills
• Hammering and chiseling in concrete and masonry; drilling in tile, wood and metal
• Chisel function with Vario Lock allows selection of different chisel positions
• Light (2.2 kg); drills up to a maximum of 20/30/13 mm in concrete/wood/metal
• Light, compact and powerful for comfortable overhead work in concrete
• The corded hammer drill PBH 2100 SRE is ideal for effortless drilling, hammering and chiseling in concrete, masonry, tile, wood and metal
• The powerful 550 W motor provides the power for the Bosch pneumatic hammer mechanism and provides a high impact force of 1.7 joules
• The SDS plus drill chuck allows accessories to be changed without tools and it allows insertion of the supplied drill chuck adapter for use of round shank drills
• An optimal working angle is guaranteed by the Vario Lock chisel function that allows 36 chisel positions to be selected
• Bosch electronic speed control delivers the right speed for the material through the pressure-sensitive switch
• Versatility for more
• Quick and easy changing of accessories
• With the SDS plus drill chuck, accessories can be changed without tools, quickly and easily with a good hold of drills and chisels
• Even more versatility
• Become even more flexible with the quick-change drill chuck
• Easy to attach, it allows comfortable drilling with straight shank drills or screwing with screw bits - perfect versatility for precise drilling in wood and metal as well as effortless screwing
• Powerful for effortless hammering in masonry
• Light for comfortable overhead hammering
• Drills easily into wood without a tapping function
• Ideal for drilling in metal without a tapping function
• Ideal for fast drilling in tiles
• Removes tiles effortlessly
• Function switch for various applications
• The function switch ensures the versatility of various modes of use, from precise drilling without a tapping function to pneumatic tapping drilling and even chiseling
• 36 variable chisel positions
• Vario Lock provides 36 variable fixed chisel positions, ensuring the optimum working angle at all times
• For continuous use
• Continuous button allows for comfortable handling in extended applications by locking the machine for continuous operation without pressing a switch

Technical data

• Power consumption: 550 W
• Output power: 270 W
• No load speed: 0 - 2,300 min-1
• Number of strokes: 0 - 5,800 min-1
• Force single stroke (EPTA): 1.7 J
• Bosch hammer mechanism: pneumatic
• Machine weight: 2.2 kg
• Max. drilling Ø in concrete: 20 mm
• Max. drilling Ø in steel: 13 mm
• Max. drilling Ø in wood: 30 mm
• Vibration emission value ah: Uncertainty K
• Hammer drilling in concrete: 14.8 m/s²: 1.5 m/s²
• Chopping: 14.1 m/s²: 1.5 m/s²
• The A-weighted sound level of the power tool is typically: sound pressure level 93.5 dB(A); sound power level 104.5 dB(A)
• Uncertainty K= 3 dB
• Measured values determined in accordance with EN 60745 total vibration values (vector sum of three directions)

Standard included

• Bosch SDS adapter drill chuck (2 609 255 708)
• Plastic case
• Depth stop (2 603 001 019)
• Additional handle (2 602 025 102)
