Norton Clipper 70184601110 TR232S Tile cutter 860 mm 230 Volt

Clipper 70184601110 TR232S Tile cutter 860 mm 230 Volt

Features TR232S

• Strong guide rail
• Tiltable rail
• Integrated saw table extension
• Collapsible handles, base and transport wheels
• Guide with adjustable cutting angle
• Easily removable saw table
• Improved cutting guide for easy and precise cutting
• Ideal for mitre cuts of 0° to 45°
• Ideal for long and wide materials
• Easy to transport and space saving
• Accurate cutting angle
• Simple water drainage and cleaning

Technical specifications TR232S

• Voltage 230V 1~ /1,1kW
• Fuse / Generator 16 amp / 3 kVA
• Max. saw blade x bore 230 x 25,4mm
• Kantelbare rail 0 - 45 graden
• Max. cutting depth at 90 / at 45 15mm / 10mm
• Max cutting length 860mm
• Dimensions saw table 860x565mm
• Toerental 2950 min-1
• Noise level / pressure level 71 dB (A) / 79 dB (A)
• Dimensions (LxWxH) 1560 x 600 x 1175mm
• Weight 61 kg

Includes

• 1 x Diamond saw blade Extreme Ceramic Turbo 230 x 25,4mm
