Ecodora 567000113 Hose reel 25m (air/water) - 200bar - hose dia. 3/8" - (4532/31)

Ecodora 567000113 Hose reel 25m (air/water) - 200bar - hose dia. 3/8" - (4532/31)

Special features

• Hose reel in ABS housing with 25m rubber compressed air hose (Ø3/8")
• ECODORA, Italian manufacturer of the highest European quality
• Features a built-in return spring to automatically roll up after each use
• Equipped with a fixed wall mounting bracket
• Significantly increases safety in the workplace by eliminating hoses lying around on the shop floor
• High quality rubber hose in metal housing
• Self-coiling with blocking
• Wide temperature range (up to max.70°C)
• High torsional resistance
• High abrasion resistance
• High chemical resistance
• Oil and hydrocarbon resistant
• Unwind system with automatic stop: protection reel damage due to impact of casing
• Multipositionable roll-off arm: quick and easy to attach to walls, ceilings, support posts and totems
• Hose guide with vertical and horizontal wheels designed to reduce hose wear and tear
• Top German quality spring (Erberle) manufactured for more than 20,000 work cycles
• Adjustable spring return force
• Synthetic rubber hose with galvanized steel fittings
• Rotating brass inlet fitting designed to reduce pressure losses
• Viton seals
• Central pivot made of galvanized steel
• In accordance with Atex 94/9 II 3 GD c X
• Supplied with suction arm 0.6m

Technical data

• Application: air/water
• Housing: ABS plastic
• Bracket: stainless steel
• Working pressure: 200 bar
• Max. temperature: 100 °C
• Length: 25 m
• Hose diameter: 3/8"
• Input: 3/8"
• Output: 3/8"
