Ecodora 567000116 Wall Reel 25M (Air/Water 70°C) - 20 Bar - Hose 1/2"

Ecodora 567000116 Wall Reel 25M (Air/Water 70°C) - 20 Bar - Hose 1/2"

Hose reel in metal housing with 25m rubber compressed air hose (Ø1/2")

Special Features

• ECODORA, Italian manufacture of the highest European quality
• Features a built-in return spring to automatically roll up after each use
• Fixed wall mounting bracket
• Significantly increases safety in the workplace by eliminating hoses lying around on the shop floor
• Unwind system with automatic stop
• Multipositionable unwinding arm
• Wide hose guide with vertical and horizontal guides designed to reduce hose wear and tear
• Removable locking position for easy maintenance and free sliding use
• Top German quality spring (Erberle) manufactured for more than 20,000 work cycles
• Adjustable spring return force
• Synthetic rubber hose with galvanized steel fittings
• Rotatable brass inlet fitting designed to reduce pressure losses
• Industrial components: self-lubricating Viton
• Central pivot made of galvanized steel
• In accordance with Atex 94/9 II 3 GD c X
• Fixed wall bracket with mounting template
• Supplied with suction arm 0.6m

Technical data

• Application:air/water
• Housing:steel
• Working pressure:20 bar
• Max. temperature:70 °C
• Length:25 m
• Dia. hose:1/2"
• Input:F 1/2" G "
• Output:M 3/8" G "

Scope of delivery

• In box
