Festool 579357 KS 120 REB-Set-AS Crosscut Saw Set 1600W

Festool 579357 KS 120 REB-Set-AS Crosscut Saw Set 1600W

Special Features

• The double-ball-bearing, dual-guide column for precise work
• Dual-line laser for precise marking of the cut line
• Front-operated fine adjustment for millimeter-precise adjustment of the saw blade angle
• Integrated special crosscut stop for cutting depths up to 120 mm
• FastFix saw blade change for material-specific cutting
• Precise cuts thanks to the dual guide column
• Flawless angle transfer with the swivel bracket and dual-line laser
• Compact and lightweight design for easy transport
• Quick-stop
• Versatile multifunctional stop for precise and safe cutting of material to size—even for the smallest pieces. Reduces the risk of material kickback

Applications

• Cutting baseboards and trim to a height of 120 mm—no calculations required
• Cutting boards and panels to size up to 305 x 88 mm
• Fitting edge profiles up to 168 mm at “any measured angle”
• Cutting beams to a thickness of 88 mm
• Easily and safely cut aluminum profiles, boards, moldings, and panels thanks to the down-pressure function
• Safely cut small workpieces and scraps without splintering—thanks to the down-pressure function and splinter guard

Technical Specifications

• Product weight without accessories: 24.30 kg
• Drive type: Mains power
• Shipping weight with accessories: 27.8 kg
• Power consumption: 1,600 W
• No-load speed: 1,400–3,600 min⁻¹
• Saw blade diameter 260.00 mm
• Cutting depth at 90°/90° 305 x 88 mm
• Cutting depth at 45°/90°: 215 x 88 mm
• Special cutting depth at 90°/90°: 60.00 x 120.00 mm
• Edge profile (diagonal cut) at 45°/90°: 168.00 mm
• Tilt angle 47/47°
• Mitre angle 50/60°
• Dimensions (L x D x H) 713.00 x 500.00 x 470.00 mm
• Cable length 3.50 m
• Dust extraction connection Ø 27/36 mm
• Special cutting depth 45°/90° (left) 40.00 x 120.00 mm
• Special cutting depth 45°/90° (right) 20.00 x 120.00 mm
• Cutting depth 50°/90° (left) 196 x 88 mm
• Cutting depth 60°/90° (right) 152 x 88 mm
• Cutting depth 45°/45° (left) 215 x 55 mm
• Cutting depth 45°/45° (right) 215 x 35 mm
• Edge profile diagonal cut at 90°/90° 168.00 mm
• Working height 900.00 mm

Scope of delivery

• WOOD UNIVERSAL HW circular saw blade 260x2.5x30 W60 (494604)
• Multifunctional crosscut fence AS-KS 120-R/L (578720)
• Swing hook (200127)
• Workpiece clamp (494391)
• Allen wrench SW 6
