Holzmann FS300_400V milling machine 400V

Holzmann FS300_400V milling machine 400V

Description

• Tilting spindle table milling machine with sliding table and outrigger table
• heavy, very high-quality overall design
• high-quality router fence with hold-down system and fine adjustment
• 4 milling speeds
• swivel spindle as standard,
• standard with under-table suction device
• Installation dimensions (L x W x H):
• 2155 x 990 x 1430 without format sliding table
• 2155 x 2400 (+1150) x 1430 with format sliding table

Technical specifications

• Motor power S1: 3000
• Motor power S6: 4000
• Voltage: 400V / 3 / 50Hz
• Table size in mm: 1000 x 350
• Table height in mm: 890
• Format sliding table in mm: 1000 x 310
• Suction connection in mm: 100
• Sound power level in dB(A): 96.8
• Sound pressure level in dB(A): 80.7
• Milling spindle diameter in mm: 30
• Milling spindle speed in min-1: 1400 / 3500 / 6000 / 8000
• Spindle stroke in mm: 130
• max. milling diameter in mm: 175
• Milling spindle tilt: (-5)0-45°
• max. clamping height in mm: 140
• Table opening in mm: 178
• max. tool diameter retractable in mm: 170 (90°), 100 (45°)
• max. tool diameter over table in mm: 200
• Milling fence in mm: 450 x 160 (L + R)
• collie: x
• Weight 280kg

Scope of delivery

• Format sliding table incl. outrigger table and cross-cut fence and spindle shaper hood.
