Holzmann TS315VF2600_400V Formaatzaagmachine

Holzmann TS315VF2600_400V Format saw machine

Description

• Robust and smooth-running parallel stop with quick attachment, guided on the stop bar
• swiveling and height-adjustable circular saw blade with prezipper
• Cast iron table with rear table extension and right side with support leg
• extendable stop with folding stop
• Support roller on the boom simplifies workpiece positioning
• Reinforced body in the area of the sliding table increases stability
• extra large cutting width to the right of the saw blade up to 1260 mm
• Equipped with a high-quality two-piece front zipper saw blade

Technical specifications

• Motor power S1: 3800
• Engine power S6: 5100
• Voltage: 400V
• Table size in mm: 800x820
• Table height in mm: 850
• Table extension in mm: 500x310 /800x440
• Size of roller table in mm: 2600x270
• Top table in mm: 760x540
• Suction connection in mm: 100
• max. cutting height 90° in mm: 100
• max. cutting height 45° in mm: 75
• max. trim length in mm: 2600
• Cutting width at the parallel stop in mm: 1200
• Saw blade (/bore) in mm: 315
• Saw blade speed in min-1: 4500
• Zipper saw blade in mm: 100
• Zipper saw blade speed in min-1: 8500
• Swing range of saw blade: 0°-45°
• Weight 340kg

Scope of delivery

• Front zipper unit
• 1xHM circular saw blade Ø315mm
• 1x HM front zipper saw blade Ø100mm
• Parallel stroke
• Telescopic stop
• Miter cutter
• Tightening clamp
