What is the Makita LS1219L 230 V chop saw best used for?

The LS1219L is perfect for fast, precise cuts on long timber, flooring, and mouldings thanks to its large 305 mm blade and extendable material supports.

How accurate is the Makita LS1219L?

It delivers millimeter precision with its integrated laser guide and locking angle gauge for clean miter and straight cuts.

How do I set the cutting angle on the LS1219L?

Use the locking pivot-head mechanism to quickly set exact angles up to 45° left or right for bevel cuts.

How does the soft-start feature benefit the LS1219L?

Soft-start reduces startup current draw, preventing circuit overload and ensuring a smooth, controlled motor launch.

Is the Makita LS1219L easy to transport?

Yes, it features a sturdy base plate, carry handle, and blade/table guards that ensure secure and damage-free transportation.

Makita LS1219L 230v Mitre Saw 305 mm

Now a total of 5 years warranty on Makita LS 1219 L Machines

on top of the Makita factory warranty (3 years after registration with Makita) you will receive an additional 2 years TOOLPLUS warranty from us. ToolNation TOOLPLUS Warranty: 2 years extra toolplus warranty on power tools

Features

Technically very extensive 305 mm radial arm saw
High accuracy
Equipped with adjustable laser line for optimal precision
Forward mounted ground steel slide bars on ball bearings for perfect guidance, allows to be placed against a wall for maximum working space
The single slide system ensures perfect cuts
Features soft start and constant speed: provides stable cutting speed in harder materials
Mitre and tilting saw for double mitre (L R)
Equipped with electronic speed control that ensures a constant speed during cutting, this ensures a high quality finish
Deep and eXact cutting Technology (DXT) makes it extremely suitable for cutting upright cornices, decorative trim and (high) skirting boards
Remaining accurate due to full adjustability
Superior dust extraction thanks to two dust ports
As best assessed by TNO
Ergonomic horizontal D-handle with soft grip for a better fit and extra comfort
Right and left extractable material supports for supporting long workpieces

Specifications

Saw blade diameter: 305 mm
Saw blade bore: 30 mm
Laser line: yes
Max. cutting cap. (height) at 0°: 107 x 363 mm
Max. cutting cap. (width) at 0°: 92 x 382 mm
Max. cutting capacity (height) at 45°: 107 x 255 mm
Max. cutting cap. (width) at 45°: 92 x 268 mm
Tilt L/R: 48 / 48º
Mitre L/R: 60 / 60 º
No load speed: 3200 min-1
Stand blade thickness: 1.8 - 1.9 mm
Volt (voltage): 230 V
Power consumption: 1800 Watts
Soft start: yes
Constant speed: yes
Electrical brake: yes
Shaft locking: yes
Soft grip: yes
Dim. lxwxh: 898x664x725 mm
Cable length: 2.5 m
Noise pressure level (LpA): 91 dB(A)
Noise pressure level (K): 3 dB(A)
Vibration ah cutting wood: 2.5 m/s²
Vibration (K) cutting wood: 1,5 m/s²
Weight (EPTA): 29.5 kg

Scope of delivery

Cloth dust bag 122852-0
Vertical Vice vertical 126617-2
Stopper above left 144922-5
Upper right stop 144925-9
Triangle ruler 762001-3
Saw blade HM 305x2.5 70T Low-n B-04606
Allen key 6 mm 781044-6
Allen key 2.5 mm 783208-8
In box
