Master BV310FS Indirectly Fired Heater 75kW

Master BV310FS Indirectly Fired Heater 75kW

Keywords

• Separate oil burner
• Electronic control light of flame with photocell
• Automatic overheating thermostat
• Safety thermostat
• Possibility of connecting a room thermostat
• Summer and winter switch that is for ventilation only
• Fuel heater
• Including trolley
• Combustion chamber made of stainless steel
• Large capacity heat exchanger
• Two oil filters: oil pump filter and squeegee filter

Technical data

• Performance: 75 kW
• Performance: 256,000 Btu / h
• Performance: 64,500 kcal / h
• Air flow rate: 4,400 m³ / h
• Fuel consumption: 6.4 kg / h
• Fuel: oil / gas
• Voltage: 220-240/50 V / Hz
• Rated current: 6.2 A
• Dimensions (L x W x H): 1500 x 620 x 1085 mm
• Net weight: 162 kg
• Diameter of the chimney connection: 150 mm
• Air outlet diameter: 1 x 450 mm
• Adjustable thermostat: possible (optional)
• Fan: axial

Standard included

• On Pallet
• Manual
