Master BV471S-4 Indirectly Fired Diesel Heater 134kW 4-way

Master BV471FS4 Indirectly Fired Diesel Heater 134kW 4-way

Special features

• AIR-BUS indirect oil-fired air heaters have a heat exchanger with stainless steel tubes and an external burner.
• They guarantee high efficiency and the ability to connect up to 4 hoses.
• Solid and durable steel frame
• Powerful axial fan
• Acquired pressure 250 Pa
• Digital combustion control
• Cold start button for cold temperature environments
• Possibility of connection to a room thermostat
• Smoke removal
• Separate Riello burner
• Summer-winter switch only for the ventilation system
• Pre-heating fuel filter
• Electronic flame control with photocell
• Safety thermostat with automatic reset
• Overheat thermostat with manual reset
• Two oil filters: tank filter and suction filter
• Quick coupling for external tank
• Air intake filter with heating option
• High-efficiency heat exchanger
• Stainless steel combustion chamber
• Sturdy wheels included
• Protection: IP 55
• 4 strong hooks for lifting

Technical data

• Capacity 134 kW
• Capacity 464000 Btu/H
• Capacity 116900 Kcal/h
• Air volume flow 8500 m3/h
• Thermostat control
• Fuel consumption 12.93 L/H
• Electric power supply 230/50 V/Hz
• Net weight 270 kg
• Diameter of chimney stream 20 cm
• Diameter exhaust 4 x 27 cm

Standard included

• Pallet
• Manual
