Metal Works 724562241 DG75E Diesel Generator 1x230V 6.0KW / 3x400V 7.5KW

MW-Tools DG75E Diesel Generator 1x230V 6.0KW / 3x400V 7.5KW

Special characteristics

• Low-noise diesel generator 6.0 kW at 1x230 V and 7.5 kW at 3x400 V, for use on the construction site, indoor or outdoor events or as an emergency generator for the company and the home.
• The power group provides a continuous power of 5.6 kW at 230 V, and is suitable for several heavy appliances to work together without overloading the fuse.
• Type 'Equal power output' with 2 separate fuses on the main board: a separate fuse for 1x230 V and for 3x400 V.
• This allows you to get the maximum power from the generator.
• Due to the double fuse, this group is also suitable for 230 V devices with an electric motor, such as construction machines (grinders, saws, etc.), workshop machines (small compressor, drill, vacuum cleaners, etc.), garden tools (lawn mower, hedge trimmer, edge trimmer, water pump, etc. .) or as an emergency generator that can provide sufficient capacity in the event of a power failure.
• Low-noise housing, fully lined with a sound-absorbing foam
• Sockets: 230V 16A (2x) and 3 x 400V 32A (1x) 2 separate fuses on the main board (1x230 V and 3x400 V) 6.0 kW maximum power at 1 x 230V 7.5 kW maximum power at 3 x 400V
• Fuel consumption at continuous full load: 2.82 litres/hour
• Electric start
• Air-cooled diesel engine 10.2hp
• AVR Voltage Regulation: Provides a stable output voltage of 230V.
• The voltage differences are within +/- 2.5%, making this generator suitable for use with most electronic devices such as construction machines, garden machines, household and kitchen appliances etc.
• Not suitable for very sensitive devices such as computers or sensitive electronics.
• 100% Copper Wound Alternator
• Digital display with display of 5 parameters: Voltage (V), Current (A), Frequency (Hz), Power (W) and hour counter Thermal overload protection
• Automatic shutdown in case of oil shortage

Technical data

• Voltage V 1x230 + 3x400
• Protection circuit
• Battery included
• Engine type Diesel 4-stroke 633cc
• Fuel consumption g/kwh 250
• Consumption l/min 0.05
• Tank capacity l 30
• 230V sockets st 2
• Sockets 3x400V st 1
• Sound level dB(A) 72
• On wheels
• Autonomy u 8.5
• Cylinder 1
• Maximum power 1 x 230V kW 6.0
• Continuous power 1 x 230V kW 5.6
• Maximum power 3 x 400V kW 7.5
• Continuous power 3 x 400V kW 7.0
• Current at 230 VA 24.3
• Current at 400 VA 10.1
• Weight kg 198.00
• Dimensions (lxwxh) mm 1030x610x830

Scope of supply

• Supplied without 15W40 engine oil
• Wheel set
• 2 lifting points, for moving with a crane
• Battery and key for the electric start
• Battery 36Ah 12V, dimensions 195 x 125 x 200 mm
