Optimum 713008253 B25 400V Column drilling machine ø 20 mm OptiDrill

Optimum 713008253 B25 400V Column drilling machine ø 20 mm OptiDrill

Features

• Column drilling machine with belt / belt drive - robust and economical
• Drilling in steel up to 20 mm
• Recording morse cone MK3
• 12 speeds
• Motor 550 Watt with aluminium housing, 3x400V
• Clockwise and anti-clockwise rotation
• Robust and cost-effective
• Guaranteed concentricity better than 0,03 mm measured in the drilling spindle
• Quiet, high-quality electric motors
• Spindle with precision ball bearing
• Smoother running due to aluminium pulleys
• The high-quality toothed drive belts give the machine significantly better power transmission and significantly lower performance losses
• Drilling depth stop
• Precision engineered work table with T-slots in diagonal pattern, swivels from -45° to 45° and rotates 360° around the column. The table is easily adjusted in height by means of a wide toothed bar
• Solid, large base plate with T-slots
• Long, ergonomic star-shaped handle with "soft grip"
• B25 also available in other voltages: 71300825 - 3x220V Note: 3x220V = power current (driving force). This is not the same as 1x230V mono = alternating current
• User-friendly control buttons with separate start and stop button and separate emergency stop
• Zero-load voltage
• Solid drill guard double window, equipped with safety switch
• V-belt cap equipped with safety switch

Specifications

• Orig. no.B25-3-400V
• Voltage V 3x400
• Power kW 0,550
• Drilling cap. in steel S235JR mm20
• Drilling capacity in continuous use S235JR mm18
• Spindle mounting MK3
• Number of speeds 12
• Spindle speed min-1210-2220
• Drilling depth mm 85
• Discharge mm 170
• Column diameter mm 70
• Table dimensions (w x d) mm 275x275
• T-slots mm 14
• Drill table swivelling angle ° /- 45
• Drilling table rotatability °360
• Distance spindle table mm 760
• Distance spindle-foot mm 1210
• Dimensions foot (w x d) mm 235x220
• T-slots base mm 14
• Weightkg 60,00
• Dimensions (l x w x h)mm 690x390x1.570

Scope of delivery

• Quick-action chuck 1-16 mm B16
• Cone cone in accordance with DIN228 MK3/B16
• 2 T-nuts for T-slot 14 mm and thread M12
• English manual, inscriptions, CE marking and CE certificate according to Machinery Directive 2006/42/CE, and EMC Directive 2014/30/CE
