Product description
Optimum Optiturn TU2807 Draaibank 230 Volt
High precision lathe for the demanding user.
Features
- Induction hardened and precision ground prism bed guides
- Guaranteed spindle nose roundness accuracy better than 0,009 mm
- Digital display of spindle speeds (Vario model only)
- High and precise finish
- Smooth-running feed drive with rounded gears, running in an oil bath.
- Selector switch right - left
- Separate emergency stop and start/stop button
- For flush turning, longitudinal turning, cone turning and thread cutting.
- Rolled trapezoidal spindle is supported by 2 sintered bearings.
- Tapered roller bearings in quality class P5
- Pressure bearings
- Strong ribbed prism bed of cast steel, induction hardened and finely ground.
- Chuck guard with microswitch, solid chisel guard and nice splash guard
- Loose head can be shifted - 5 mm for turning cones.
- A set of exchangeable wheels provides a wide range for thread cutting.
- With a feed shaft for thread cutting or automatic longitudinal turning.
- Powerful, maintenance-free motor.
- Constructed according to DIN8606.
- Other voltages available on request 3x220V/50Hz and 3x440V/60Hz
- Note: 3x220V = power current (driving power). This is not the same as 1x230V mono = alternating current.
Technical data
- Voltage V 1x230
- Motor power kW 0,85
- Center height mm 140
- Center distance mm 700
- Turning diameter above bed mm 266
- Turning length in the bed bridge mm 180
- Bed width mm 180 Cup
- Number of speeds 6
- Spindle speed min-1 150-2,000
- Spilkonus MK 4
- Spilboring mm 26
- Wire steps and power supply
- Longitudinal feed mm/O 0.07-0.2
- Thread cutting metric M 0,2-3,5
- Thread cutting inch Gg/1 56-8
- Guide and trolley
- Travel distance chisel slide mm 60
- Traversing distance cross slide mm 160
- Height of chisel holder mm 13,5
- Loosele kop Cone losse kop MK 2
- Heading loose head mm 85
- Weight kg 180,00
- Dimensions (l x w x h) mm 1,370x640x535
Includes
- Chuck with 3 claws 125 mm
- Fixed center point MK2
- Fixed center point MK4
- Meenemer
- Chuck and chisel guard, splash guard and swarf container
- 4-fold chisel holder
- Wisselwielen set
- Control keys
- Afnameprotocol
- Dutch language manual, inscriptions, CE-mark, and CE-declaration according to Machinery Directive 2006/42/CE, Low Voltage Directive 2006/95/CE and EMC Directive 2004/108/CE.
More Information
EAN | 4030635003899 |
---|---|
Ordernumber | 713427001 |
Manufacturer | Optimum |
Voltage | 230 V |
Warranty | 1 year |
