Optiturn 713403010 TM3110 Metal lathe 400V 1.1 kW Center distance 1000 mm spindle bore 38 mm

Optiturn TM3110 Metal lathe 400V 1.1 kW Center distance 1000 mm spindle bore 38 mm

Special features.

• Longitudinal and transverse feed: The machine features both longitudinal and transverse feed for automatic and consistent turning, essential for perfect surface quality
• Precision: guaranteed concentricity accuracy of the spindle nose better than 0.015 mm and concentricity accuracy of the chuck better than 0.04 mm
• Robust bed: The highly ribbed prism bed is made of gray cast iron, induction hardened and precision ground
• Loose head functionality: The loose head can be moved ±5 mm for turning cones, complete with quick clamp lever and precision reading of 0.02 mm
• Guides: Induction hardened and precision ground prism bed guides. All guides are adjustable with V keys.
• Drive: Smooth-running feed drive with rounded gears, running in an oil bath
• Feed shaft: With a feed shaft for threading or automatic longitudinal turning. Automatic longitudinal / transverse spindle drive
• Operation: Selector switch clockwise - counterclockwise
• Spindle: Roller-rolled trapezoidal spindle is supported by 2 sintered bearings, supplemented by thrust bearings

Technical data

• Voltage: 3x400 V
• Power: 1,1 kW
• Capacities
• Center height: 155 mm
• Center distance: 1000 mm
• Turning diameter above bed: 323 mm
• Turning diameter above slide: 216 mm
• Bed width: 190 mm
• Number of speeds: 9
• Spindle speed: 65 - 2,000 min-¹
• Spindle nose: MK 5
• Spindle nose Camlock: DIN55029 D1-4"
• Spindle bore: 38 mm
• Thread steps and feed
• Longitudinal feed: 0.02 - 0.4 mm/O (24 positions)
• Transverse feed: 0.01 - 0.2 mm/O (32 positions)
• Thread cutting metric: M 0.4 - 10 (29 steps)
• Threading inch: 56 - 4 Gg/1"
• Travel of chisel slide: 90 mm
• Travel path of cross slide: 168 mm
• Height of chisel holder: 16 x 16 mm
• Cone loose head: MK 3
• Heading single head: 100 mm (Ø38)
• Product information
• Length: 1749 mm
• Width: 740 mm
• Height: 566 mm
• Weight: 350 kg

Scope of delivery

• Chuck with 3 chucks 160 mm
• Fixed center points MK3 and MK5, and reduction sleeve
• 4-fold chisel holder for chisel inserts up to 16 x 16 mm
• Change wheel set
• chuck and chisel guard
• splash guard and chip guard
• operating keys
• Supplied with Dutch manual and CE certificate in accordance with Machine Directive 2006/42/CE and EMC Directive 2014/30/CE
