Proxxon 24002 PD 250/E Precision lathe 230 Volt

Proxxon 24002 PD 250/E Precision lathe 230 Volt

Features PD 250/E

Machinebed:

• Machine made of cast steel with wide prism ring for vibration-free machining
• A flange for mounting the milling machine is attached at the back
• Covered lead screw

Main spindle:

• Made of cast aluminium
• Precision bearing main spindle 10.5 mm aperture
• Hollow drill head side 70 mm to 14 mm
• With MC 2 recording
• Rotary switch for the attachment of the automatic feed to the screw

Losse kop:

• Made of cast aluminium
• Pinole Ø 20 mm, extendable to 30 mm
• With millimetre scale, MC 1 holder and rotating centre

Drive:

• Quiet DC motor with a 3-speed belt drive for 300 - 900 and 3000/min
• With additional speed control, depending on the belt transmission, infinitely variable 100 - 300 or 1000/min
• Clockwise and anti-clockwise rotation
• Relay switch with emergency stop function

Chucks:

• High quality 3-jaw chuck according to DIN 8386 class 1
• Clamping range of reversible jaws 2 - 75 mm
• The rotating drill head is equipped with a safety cut-out

Thread cutting device:

• Interchangeable wheels for left and right-handed threads

Handwiel:

• Made of aluminum with adjustable scale (1bar = 0.05 mm, 1 stroke = 1 mm)

Other Technical Data

• Weight: 12 kg
• Dimensions: L 560, T 270, H 170 mm
• Distance between centers: 250 mm
• Center height: 70 mm
• Center height above support: 43 m
