Ridgid 48118 SeeSnake® Compact2 camerasysteem

Ridgid SeeSnake® Compact2 camerasysteem

Features

• Big performance in a compact, durable package.
• Designed for the inspection of pipes from 1.5" to 6" (40 mm to 150 mm), the Compact2 has a 100" (30 m) push cable, a 1" (25 mm) self-leveling camera head and a probe.
• Thanks to the quick release feature of the CCU docking system, set-up is fast and easy
• Flexible pushcable moves easily through several sharp bends
• Self-leveling camera for a clear, sharp, always upright image of the pipe
• Built-in probe for locating a key spot during pipe inspection.

Technical data

• Pipework capacity 1.5" to 6" (40 cm to 150 mm)
• Pushcable length 30 m
• Diameter push cable 0.26" (6 mm)
• Core thrust cable 0.14" (3.5 mm) fiberglass
• Minimum bend radius push rope 2.5" (63.5 mm)
• Weight (without batteries) 16.6 lbs. (7.5 kg)
• Size Length 25" (63.5 cm), Width 14" (35.6 cm), Height 17" (43.2 cm)
• Type of camera 1" (25 mm) self-levelling
• Resolution 648 x 488 (NTSC), 768 x 576 (PAL)
• Light source 6 LEDs Probe 512 Hz
• Operating temperature 0°C to 40°C
• Storage temperature -10°C to 70°C
• Input protection without monitor IPx5

Includes

• 45168 - CS6Pak digital recorder (230 V)
• 48098 - SeeSnake Compact2, reel only (230 V)
• 43328 - 18 V 4.0 Ah Li-ion battery pack
• 43333 - 230 V Advanced Lithium-oplader
