Rotec 321.4800B HSS-E OPTI-LINE machine tap DL DIN 376B M48x5,0

Rotec 321.4800B HSS-E OPTI-LINE machine tap DL DIN 376B M48x5,0

Features

• HSS-Co machine tap DIN 376, metric [M], 60°, thin shank, type B with peeling cut (up to M16) or long cut (>M16)
• For tapping through holes in (alloy) steel
• Material groups : 1.1 - 1.2 - 1.3 - 1.4

Specifications

• d1: M48
• P : 5,0
• l1 : 250
• l2 : 70
• d2 : 36,0
• a : 29,0
• Material : HSSE
• Surface : Blank
• Type of hole : Continuous
• Type of tap : Machine tap
• DIN : DIN 376
