Rotec 336.1400C HSS-E PM 1200 machine tap BL DIN 376C/45° M14x2,0

Rotec 336.1400C HSS-E PM 1200 machine tap BL DIN 376C/45° M14x2,0

Features

• HSS-E PM Machine stud DIN 376, metric [M], 60°, 6HX, thin shank, type C with helix angle 45°
• The thin but wear-resistant HardLube® coating with low friction coefficient ensures higher cutting speeds and longer service lives
• Universal high performance tapping for blind holes in (alloy) steel
• Materiaalgroepen : 1.1 - 1.5, 2.1 - 2.3, 3.1 - 3.3, 4.1 - 4.10, 5.1, 5.3

Specifications

• d1 : M14
• P : 2
• l1 : 110
• l2 : 20
• d2 : 11,0
• a : 9,0
• Material : HSS-E PM
• Surface : Coated (Hardlube)
• Type of hole : Blind
• Type of tap : Machine tap
• DIN : DIN 376
