Rotec 347.1600 HSSE-PM 1400 Machine stud DIN 376B M16 TiCN

Rotec HSSE-PM 1400 Machinetap DIN 376B M16 TiCN

Features

• High-performance HSS-E-PM (powder metallurgy) red ring machine tap DIN 376, metric [M], 60°, ISO2 (6H), thin shank, type C with peeling cut, TiCN coating for longer tool life and higher cutting conditions
• PM taps have a very high toughness with a very high wear resistance
• For tapping through holes in (high) alloy steel
• Material group: 1.1 to 1.6 - 3.2 - 3.3

Technical data

• d1 : M16
• P : 2
• l1 : 110
• l2 : 32
• d2 : 12,0
• a : 9,0
• Material : HSSE-PM
• Surface : Coated (TiCN)
• Type of hole : Continuous
• Type of tap : Machine tap
• DIN : DIN 376
