Rothenberger 1000001135 Ropuls eDM Flushing Compressor

Rothenberger 1000001135 Ropuls eDM Flushing Compressor

For installers and users in the building service the ROPULS eDM flushing compressor is ideal for cleaning and dehumidification of heating systems, for flushing drinking water pipes according to DIN 1988-2/EN 806-4 and for disinfection of drinking water pipes. A protocol created by an app can be sent immediately by email as a PDF with company headings and all relevant data.

Features

• Flushing of floor heating / heating loops
• Flushing of drinking water pipes according to DIN 1988-2
• Two rinsing modes (pulse function and continuous rinsing) for good rinsing results
• Compact dimensions and practical undercarriage make it easy to use on the building site and easy to transport
• 2 flush modes (pulse function and continuous rinsing) for a good flushing result
• Easy operation thanks to clear operator panel
• Easy and professional creation of a flushing protocol in PDF by means of free APP
• Additional ROCLEAN® Functions:Cleaning & protection of heating circuits

Specifications

• Pipe connection: R 3/4
• Max. pipe diameter: DN 65 /2
• Max. flow: 5 m3 /h
• Max. Water pressure: 7 bar
• Max. Water temperature: 30 °C
• Beschermingsklasse: IP 22
• Oil separation rate: 99.9%
• Particle reduction: 0.3 ?m Compressor
• Max. operating pressure: 8 bar
• Motor power: 1.1 kW
• Mains connection: 230 V - 50 /60 Hz
• Dimensions ( H x W x D ): 630 x 380 x 340 mm

Includes

• 2 x 1 meter pipe with 3/4" connection
• Manual
