Union 1AB/EM25U Pneumatic stapler for EM staples 12-25mm

Union 1AB/EM25U Pneumatic stapler for EM staples 12-25mm

Suitable for : aluminum strips, tin strips, hardboard, corner strips, particle board and all materials to be stapled up to a thickness of approx. 10 mm. Application : coffin industry, clog industry, furniture industry, rattan industry, system construction, home furnishing.

Special features

• 360 degree rotatable air outlet
• Very handy tacker
• Trouble-free underloading system
• Point protection
• Standard delivered in sturdy plastic case
• Thermo handle
• Extended nose (24 mm)
• Very fast in use
• Very quick to load

Technical data

• Suitable for stapling: Yes
• Width: 60 mm
• Back width: 5.05 mm
• Length: 230 mm
• Minimum Suitable for leg length staples: 6 mm
• Maximum Suitable for leg length staples: 16 mm
• Height: 190 mm
• Air inlet device side: R 1/4"
• Magazine capacity: 110
• Min. Working pressure: 4.5 bar
• Max. working pressure: 7 bar
• Impact strength adjustable: No
• Air consumption per stroke (l): 21
• Weight: 1.2 kg
• Empty shot protection: Yes
• Magazine type: Bottom loader
• Air outlet adjustable: No
• Max. operating pressure: 101.5 psi
• Air consumption at 6bar, 60 shots/min: 21 l
• Max. operating pressure (bar): 7 bar

Scope of delivery

• 1x tacker
• 1x instruction manual
• 1x tacker oil
• Allen wrenches
