Union 3AH/IZ45R Pneumatic roofing tacker IZ nails 19-45mm

Union 3AH/IZ45R Pneumatic roofing tacker IZ nails 19-45mm

Suitable for : asphalt shingles, roofing, cardboard on pallets, rubber and many sheet materials up to a thickness of about 15 mm. Application o. a. : log cabin construction, construction, caravan industry, roofers, box industry, pallet industry, carpentry industry, packaging industry.

Special features

• 180 degree rotatable air outlet
• Point protection
• Adjustable depth setting
• Standard delivered in sturdy plastic case
• Thermo handle
• Adjustable stop on magazine
• Very fast in use.

Technical data

• Suitable for nails: Yes
• Width: 114 mm
• Length: 272 mm
• Minimum nail length : 19 mm
• Maximum Nail Length : 45 mm
• Height : 284 mm
• Air inlet device side: R 1/4"
• Magazine capacity: 120
• Min. Working pressure: 4.8 bar
• Max. working pressure: 7.6 bar
• Impact strength adjustable: Yes
• Air consumption per stroke (l): 72
• Weight: 2.5 kg
• Empty shot protection: Yes
• Air outlet adjustable: Yes
• Max. operating pressure: 110.2 psi
• Air consumption at 6bar, 60 shots/min: 72 l
• Max. operating pressure (bar): 7.6 bar

Scope of delivery

• 1x tacker
• 1x instruction manual
• 1x tacker oil
• Allen wrenches
