VIRAX 137571 Portable electric wire cutting machine Phenix IV 230 V

Virax 137571 Portable electric wire cutter Phenix IV 230 V

Special features

• Fast threading: 4 times faster return after threading thanks to the adaptive gearbox.
• Suitable for all situations: threading close to walls and in tight spaces possible thanks to optimized ergonomics and head with staggered drive.

Technical data

• Fast and efficient thread cutting: Realization of BSPT or NPT threads on steel pipes (1⁄4" to 2⁄4") in workshop or construction sites.
• Time saving: Adaptive gearbox allows 4x faster return, full cycle of 1 minute for 2" tube.
• Ease of use: Anti-coupling bar prevents rotation of the machine during threading.
• Quick locking system: heads from 1/4" to 1.1/4" with tool-free adapter, and 1.1/2" and 2" with integrated locking ring.
• Durability: Gearbox with induction-hardened gears and ball bearings for minimal wear.
• 230 V version: Universal motor of 1010 W for continuous operation, 2.8 meters cable.
• 18 V CAS battery version: Mobile and efficient with maintenance-free brushless motor.
• CAS batteries: Long service life through permanent cell monitoring and ventilated charger, charge indicator, and long-term storage without discharge.
• Rotational speed: 25-15 tr/min (thread cutting), 58 tr/min (fast return).
• Standards: Pipes must comply with EN 10255 S and W, light series (tarif 1 & 2) is not recommended.

Scope of delivery

• Screw Clamp (ref. 137575).
• Adapter for heads 1/4" to 1.1/4" (ref. 137576).
• Virabox case.
