Wacker Neuson 5100030746 HMS-Set 425 Handpole Vibratory Needle 45mm 230V 5m

Wacker-Neuson 5100030746 HMS-Set 425 Hand Stick Vibrating Needle 45mm 230V 5m

Special features

• The HMS series convinces with flexibility and economy: The poker vibrators of this product series are individually configurable with different shafts, poker vibrators and motors.
• All devices have a quick-lock coupling for easy and fast handling as well as lightweight, well portable motors.
• The vibrators are induction-hardened and therefore offer high wear resistance. Thus, the HMS series offers flexible adaptability to the requirements on any construction site.

Highlights

• Modular system: Thanks to the modular design, the device can be configured for any application.
• Only one drive unit is required to use poker vibrators of different sizes. This saves on purchase and maintenance costs.
• Speed-stable, high-traction electric motor: With its consistently high speed, this high-frequency poker vibrator achieves reliable compaction performance, ensuring high-quality results and efficiency.
• The motors were developed by Wacker Neuson and are wound and manufactured at the company's own production facility in Germany. This guarantees consistently high engine performance and quality.
• Very good operating weight: The drive unit delivers high performance at low weight and therefore offers high operating comfort.
• A multitude of versions: A large selection of different bottle sizes, flexible shafts and motors enables a wide range of applications. This means that a solution can be found for every construction site, even for extreme requirements.
• Needle head fully hardened: The needle head is fully hardened. This makes it particularly robust and prevents rapid wear and tear.
• Made in Germany: A high standard of quality, great motor power and long service life are guaranteed because the device was developed and manufactured in Germany.
• Durability of the carbon brushes up to 500 operating hours.
• The carbon brushes have a very long service life of up to 500 operating hours. This means that in practice the device is usually maintenance-free, as the operating life is often less than this number of hours.
• Quick-change coupling: The flexible shafts can be changed without tools with a few operations. This allows the device to be configured very quickly for any need.
• The high-quality coupling ensures optimum power transmission.

Technical data.

• Bottle diameter 45 mm
• Bottle length 385 mm
• Hose length 5 m
• Rated current 7.8 A
• Rated voltage 230 V
• Weight 5.9
• Motor power 1.8 kW
• Cable length 5 m
• Frequency 50-60 Hz
• Dimensions motor LxWxH 312x151x230 mm

Scope of delivery

• HMS external vibrator
• Hose 5m
• Vibration bottle 45 mm
• Manual
