Wacker Neuson 5100060825 DPU5260Heh Reversible vibratory plate with diesel engine Hatz 600 mm 52 kN

Wacker-Neuson 5100060825 DPU5260Heh Reversible vibratory plate with diesel engine Hatz 600 mm 52 kN

Special features

• Efficient and precise compaction of trenches and surfaces
• The medium-duty reversible vibratory plates offer the perfect combination of high forward and reverse speeds and excellent compaction performance.
• They were specially developed for trench and surface compaction requirements and enable efficient and precise compaction of different soil types and structures.
• With their modern and ergonomic user surface, they offer the highest level of comfort and facilitate operations, which visibly leads to productivity increases.
• The diesel-powered Pro version also impresses with a powerful machine control with innovative functions: Bluetooth connectivity via smartphone app, standard
• compaction control and optional compamatica and telematics functions.
• Numerous machine diagnostic functions also simplify service and maintenance, for seamless operation and a long service life of your machine.

Highlights

• Optimal control and ergonomics
• Low hand-arm vibrations (< 2.5 m/s²)
• Compamatic
• Digital machine control
• Easy cleaning thanks to open base plate

Technical data

• Centrifugal force 52 kN
• Ground capacity 1,008.0 m2/h
• Headway 28.0 m/min
• Vibration (Hz) 69.0 Hz
• Length of base plate 900.0 mm
• Width 600.0 mm
• Base plate width 600.0 mm
• Height 1,449.0 mm
• Safety frame height 877.0 mm
• Thickness of base plate 15.0 mm
• Operating weight 404.0 KG
• Ground clearance 877.0 mm
• Effective power 7.3 kW
• Rated motor speed 2,800.0 1/min
• HAV vibration value (average value) 2.5 m/s2
• HAV vibration value (standard) EN 500-4

Scope of delivery

• Operating instructions
