Eibenstock 10.093.31 Diamond drill wet/dry ETN 162/3 2200W - up to 162 mm in concrete with 3 speeds

Eibenstock 10.093.31 Diamond drill wet/dry ETN 162/3 2200W - up to 162 mm in concrete with 3 speeds

Dry drilling in sand-lime brick, brickwork, clinker, brick and other abrasive materials as well as wet drilling in reinforced concrete, natural stone and asphalt

Features

• Professional 3-speed diamond drill from the new generation of machines, for drilling by hand or with drill stand
• Oil bath lubricated gear housing, combi shaft and integrated dust extraction or water supply, electronically adjustable switch, thermal and overvoltage protection, mechanical slip clutch, PRCD switch and additional adjustable handle
• Powerful 2200 W motor with high power reserves and a long lifetime
• Service indicator - lights up approx. 10 working hours before the carbon brushes need to be replaced
• 3-speed oil bath gearbox - for optimal lubrication in all working positions due to the specially developed oil pump and optimal adjusted torque-speed-ratio for all diameters
• Combination spindle with integrated connection for centering rod - fast, precise spot drilling
• Ergonomic handle with large-dimensioned switch button - good control and effortless working
• PUR-construction site cable - strong for heavy duty use
• Changing system - fast conversion between wet and dry applications
• Packed in plastic case
• Integrated levels on machine and handle
• Quick-mounting system - fixing of the machine including handle into the rig without any tools

Technical data

• Power input: 2200W
• Rated voltage: 230 V
• Rated speed: 0-510 | 0-1150 | 0-2500 rpm.
• No-load speed​: 800 | 2200 | 4000 rpm.
• Spindle connection: combi main shaft 1¼" male - G½" female
• Drilling diameter (wet): 12-162 mm
• Drilling diameter (dry): 12-202 mm
• Collar diameter: 60 mm
• Weight: 6.7kg

Standard delivery

• Adjustable handle
