Eibenstock 10.094.38 Drill stand BST 182 V/S for drills up to 202 mm with ETN 162/3 & PLD 182.1 NT

Eibenstock 10.094.38 Drill stand BST 182 V/S for drills up to 202 mm with ETN 162/3 & PLD 182.1 NT

Aluminum diamond drill stand with wide continuous teeth. Particularly light, handy and easy to operate due to the scale on the column.

With combination foot for plug or vacuum attachment (not included) and robust leveling bolts. With quick coupling for diamond drilling machine ETN 162/3.

Features

• For core drillings in the whole construction industry up to 202 mm
• Machine connection - quick-mounting adapter
• Scale - easy adjustment of drilling depth
• Toothing - wide and constant, precise, long-lived
• Aluminium colum with braces - high torsional strength, light, 45° swivel
• Adjusting screws - robust, exact adjustment
• Hole centre indicator - exact positioning
• Guides/bearings - smooth running, hard-wearing, adjustable
• Spirit level - easy to level
• Feed lever - change without any tool, easy selection of the operating side
• Rollers - quick to mount, easy and light transport (accessory)
• Base - Combined base (anchor or vacuum)

Technical data

• Connection (machine): quick release coupling
• Foot dimensions: 320 x 250 mm
• Weight: 14 kg
• Suitable for: ETN 162/3 & 182.1 NT
• Adjustment angle: up to 45 degrees, with support degrees
• Length: 995 mm
• Max. drilling diameter: 202 at 90 degrees mm

Standard delivery

Inlcuding

• Combi foot
• Quick coupling for diamond drilling machine ETN 162/3

Excluding

• Vacuum attachment
