Fein 90318223000 Magnetic drill stand MBS 16 X (excl. machine)
Order your Fein machine now and take advantage of the total 5 year warranty on Fein machines(*)
(*) In addition to the Fein manufacturer''s warranty (3 years after registration with Fein) you will receive an additional 2 years TOOLPLUS warranty from us. ToolNation TOOLPLUS Warranty: 2 years extra Toolplus warranty on power tools, extra security from Toolnation.
Features
- Flexible magnetic drill stand with fine adjustment for rotary drills up to a drill size of 16 mm
- Lightweight, compact magnetic drill stand for universal use such as drilling, thread cutting, reaming and countersinking
- Double drill motor guide for using the largest drilling tools
- High magnetic holding force and safety switch guarantee safe working in any position
- Integrated coolant tank with flexible hose. Supply handwheel that can be changed sides
- Adjustable carriage height without tools
Specifications
- Nom. power consumption 100 W
- Socket max. 16 A
- Cable with plug 4 m
- Weight according to EPTA 9,5 kg
- Spiral drill max. Ø 16 mm
- Taps M 12
- Galvanizing max. Ø 50 mm
- Reaming max. Ø 16 mm
- Magnetic holding force 12 500 N
- Stroke 145 mm
- Up to 325 mm stroke range
- Dimensions magnetic base 195 x 90 mm
- For clamping shaft Ø 43 mm
- 230V X
Includes
- 1 refrigerant tank
- 1 sjorband
- 1 contact protection
