Gys 5192030794 GYSMI 200P Welding inverter set in case

GYS 5192030794 GYSMI 200P Welding inverter set in case

GYS welding machine GYSMI 200P with inverter technology is controlled by a microprocessor. The dynamic arc of this product is revolutionary and unique on the market. The 200P is suitable for all types of electrodes: rutile, basic, stainless steel, cast iron on direct current. Compact, very convenient thanks to low weight (5 kg), small size and low energy consumption.

Special features

• Instant arc ignition thanks to high no-load voltage
• Constant welding power
• Very soft arc due to direct current
• Insensitive to mains voltage variations or arc length
• Very good penetration and perfect arc stability
• HOT START - start current increase at switch-on.
• ANTI STICKING - prevents sticking and annealing of the electrode.
• ARC FORCE - prompt current increase in difficult welding situations.

Technical Data.

• Type: Inverter
• Model: MMA welder
• Connection voltage: 230 V
• Length: 270 mm
• Width: 180 mm
• Height: 140 mm
• Frequency: 50/60 Hz
• Number of phases: 1
• Weight: 5 kg
• Max. amperage: 200 A
• Degree of protection (IP): IP21
• Fuse rating (slow blow): 32 A
• Operating temperature: -10 / 40 °C
• Continuously adjustable: No
• Max. load capacity at 100% (electrode): 200 A
• No-load voltage: 72 V
• Welding current (electrode): 10 / 200 A
• Welding voltage (electrode): 20.4 / 28 V
• Suitable for tungsten electrode diameter: 1.6 / 5 mm

Scope of delivery

• GYSMI 200P
• Return cable (1.6m / Ø16mm²)
• Electric cable (2m / Ø16mm²)
