Mafell 915503 SKS130 Door Lock Chain Mortiser , 18 mm chain attachment

4032689136479
Articlenr.
915503
In stock, shipping within 2 working days
3,348.07 2,767.00 Excl. VAT
Mafell 915503 SKS130 Door Lock Chain Mortiser , 18 mm chain attachment - 2
Mafell 915503 SKS130 Door Lock Chain Mortiser , 18 mm chain attachment - 1 Mafell 915503 SKS130 Door Lock Chain Mortiser , 18 mm chain attachment - 2 Mafell 915503 SKS130 Door Lock Chain Mortiser , 18 mm chain attachment - 3 Mafell 915503 SKS130 Door Lock Chain Mortiser , 18 mm chain attachment - 4 Mafell 915503 SKS130 Door Lock Chain Mortiser , 18 mm chain attachment - 5 Mafell 915503 SKS130 Door Lock Chain Mortiser , 18 mm chain attachment - 6 Mafell 915503 SKS130 Door Lock Chain Mortiser , 18 mm chain attachment - 7 Mafell 915503 SKS130 Door Lock Chain Mortiser , 18 mm chain attachment - 8
Product description

Mafell 915503 SKS130 Door Lock Chain Mortiser, 18 mm chain attachment

Now a total of 5 years warranty on Mafell SKS 130 machines

Now a total of 5 years warranty on machines after registration of your machine, using the enclosed warranty form.

Features

  • The SKS 130 is the world's first mobile machine for inserting lock cases
  • The safety requirements of homeowners and residents have increased significantly in recent years
  • That is why more and more security locks are being installed
  • With an output of 1600 Watts, the SKS 130 mills lock cases of any size completely shatterproof!
  • With a large and stable clamping surface, the SKS 130 is clamped to the door
  • The pertinax and rubber coating of the clamping device keeps the door surface undamaged

Specifications SKS 130

  • Cutting depth 145 mm (130 mm)
  • Stitch width 18 mm
  • Stitch length 78 mm
  • Stroke 175 mm
  • Speed (no load) 5770 r/min
  • Speed (laden) 4370 r/min
  • Cutting speed 8,6 m/s
  • Universal motor Voltage 230 V Frequency 50/60 Hz
  • Power consumption 1600 W
  • Power consumption 950 W
  • Weight 10,0 kg
  • Suitable for use on site or in the workshop

Includes

    • Chain Mortiser SKS 130 Order No. 915 501
    • Comes with: 2 Guide rails Best. No. 091 000
    • 2 Cutter chains Order No. 091 001
    • 2 Sprockets Order No. 091002
    • 1 Hexagonal screwdriver SW 5 Order No. 093 278
    • 4 m Cable with plug Order No. 087 323
    • 1 Transport box
More Information
More Information
EAN 4032689136479
Ordernumber 915503
Manufacturer Mafell
Voltage 230 V
Warranty 5 years
