Makita HB501 50 mm 230V Magnetic Core Drill in a Case

Makita HB501 50 mm 230 V Magnetic Core Drill in Carrying Case

Powerful 230 V magnetic core drill for drilling holes up to 50 mm in metal. The drill features a magnetic clamping force of 12,000 N and two speed settings for optimal adaptation to the application.

Special Features

• Suitable for core drilling in metal up to 50 mm in diameter.
• Powerful magnetic base for stable positioning during drilling.
• Two speed settings for optimal adaptation to various applications.
• Weldon chuck for core drills.
• Integrated drill stand and magnetic base.
• Compact design for easy access to the workpiece.

Technical Specifications

• Voltage: 230 V
• Power consumption: 1200 W
• Magnetic clamping force: 12,000 N
• Core drill diameter: 12–50 mm
• Connection: Weldon
• No-load speed, setting 1: 450 min⁻¹
• No-load speed, setting 2: 750 min⁻¹
• Drilling depth: 50 mm
• Weight: 17.5 kg
• Dimensions L × W × H: 270 × 156 × 432 mm
• Cable length: 2.8 m

Scope of delivery

• 1x 3 mm offset Allen wrench (783201-2)
• 1x 4 mm offset Allen wrench (783202-0)
• 1x 2.5 mm angle Allen wrench (783208-8)
• 1x 5 mm angled Allen wrench (783217-7)
• 1x Fuse 5 × 20 mm, 2 A (ES00000035)
• 1x Safety strap (ES00000074)
• 1x Centering pin 6 × 104 mm (ES00000075)
• 1x Centering pin 8 × 105 mm (ES00000076)
• 1x Storage bin for consumables (ES00000077)
• 1x 8 mm combination wrench (ES00000078)
