Makita HR009GU201 XGT 40V Max Cordless Combination Hammer, 30 mm, with 2 x 40V 4.0Ah batteries and a fast charger + dust extraction system in a plastic case

Makita HR009GU201 XGT 40V Max Cordless Combination Hammer, 30 mm, 2x 40V 4.0Ah batteries and quick charger + dust extraction system in a plastic case

The XGT 40 V Max combi hammer is compatible with SDS-PLUS drill bits and chisels, and its interchangeable chuck is suitable for drilling, hammer drilling, and light demolition work. The brushless motor delivers performance comparable to a corded model, while the low vibration level and variable speed control contribute to comfortable and precise operation. The tool is designed for dust-free drilling when used with a dust extraction unit and optionally supports the Auto-start Wireless System (AWS) for wireless communication with a cordless vacuum cleaner. Thanks to its dust and moisture protection (XPT), the combi hammer is suitable for use in a wide range of working conditions.

Special features

• XGT 40 V Max combi hammer with SDS-PLUS connection and interchangeable drill chuck.

• Equipped with an efficient BL motor that delivers the power and performance of its corded equivalent, the HR3012FCJ.

• In the event of a sudden drop in RPM or if the drill bit becomes jammed in the material, Active Feedback Sensing Technology (AFT) activates and shuts off the machine.

• Pre-configured for the Auto-start Wireless System (AWS) for wireless communication between the cordless tool and the cordless vacuum. The optional AWS unit WUT01 is available as an accessory (198900-7).

• Equipped with electronics for constant speed and variable speed control.

• Ideal combination hammer for holes up to 22 mm, but can drill up to 30 mm in concrete.

• When used with the DX11 dust extraction unit, the maximum drilling length, including the SDS-PLUS connection, is 265 mm.

• Low vibration level thanks to Anti-Vibration Technology (AVT), 7.8 m/s² when drilling in concrete (lower than the HR3012FCJ).

• Combi hammer with three functions: drilling, hammer drilling, and light demolition work.

• Impact energy (3.9 joules) is equivalent to that of the corded H3012FCJ.

• Variable speed control in the switch for a smooth and clean start to drilling.

• Integrated LED light for better visibility of the work area.

• Equipped with two interchangeable drill chucks: an SDS-PLUS and a quick-release chuck.

• Drilling and dust extraction in one.

• Suitable for outdoor use; well-protected against dust and moisture ingress thanks to eXtreme Protection Technology (XPT).

• Durable, energy-efficient, and maintenance-free brushless motor with electronic control.

• Communication between the tool and the battery maximizes the tool’s performance and battery safety.

Technical Specifications

• Platform: XGT 40 V Max

• Connection/chuck: SDS-PLUS

• Impact energy (EPTA): 3.9 joules

• Ideal drilling range in concrete: 10–22 mm

• Concrete drill bit: 4–30 mm

• Core bit: 35–90 mm

• Diamond drill bit: 32–80 mm

• Metal drill bit: 1.5–13 mm

• Wood drill bit: 3–20 mm

• Wood twist drill: 6–32 mm

• Interchangeable drill chuck: Yes, 1.5–13 mm

• Rotational speed: 0–840 rpm

• Impact rate: 0–4,500 min⁻¹

• Motor: BL motor

• Number of mechanical speeds: 1

• Constant speed: Yes

• Safety slip clutch: Yes

• Lighting: Yes

• Soft grip: Yes

• Dimensions (L × W × H): 457 × 97 × 263 mm

• Weight: 4.3 kg

• Weight with XGT BL4020 battery: 5.3 kg

• Weight with XGT BL4080(F)(H) battery: 6.7 kg

• Sound pressure level: 94 dB(A)

• Sound power level: 105 dB(A)

• Vibration when hammer drilling in concrete: 7.3 m/s²

• Vibration when chiseling with side handle: 7.1 m/s²

Package Contents

• 1x BL4040F XGT 40 V Max 4.0 Ah battery (1910N6-8)

• 1x XGT DC40RA fast charger (191E07-8)

• 1x Quick-release drill chuck 1.5–13 mm (191F46-4)

• 1x Dust extraction adapter with collection container DX11 (191G00-4)

• 1x Depth stop for drill and combi hammer (331886-4)

• 1x Protective cap for XGT batteries (412393-7)

• 1x Plastic carrying case (821875-2)

• 1x Drill and chisel grease 100 ml dispenser (198993-4)

• 1x Feed sleeve for DX10, DX11 (459206-1)
